Marvel F2150PC3 Automatic Vertical Band Saw
Marvel F2150PC3 Automatic Vertical Band Saw
Location:Pennsylvania
or
Call 1-262-284-5611
Description
Control: Marvel PC3 CNC Control, Coolant System: Built-In w/ Flood System (60 Gallon Capacity), Hydraulic Oil: 10 Gallons, Work-Rest Rollers: (2) Turned Ball Bearing Rollers, Entry/Discharge Side, Material Index Mechanism: Shuttle Vise
Specifications
| Manufacturer | Marvel |
| Model | F2150PC3 |
| Year | 2015 |
| Condition | Used |
| Stock Number | 3712 |
| Main Drive Motor | 10 HP |
| Nominal Round | 20" |
| Blade @ 45 Degree Rounds | 17" |
| Blade @ 60 Degree Rounds | 11.25" |
| Nominal Rectangles | 20" x 25" |
| Blade @ 45 degree Rectangles | 20" x 17" |
| Blade @ 60 Degree Rectangles | 20" x 11.25" |
| Speed Range (Infinitely Variable) | 30 - 500 FPM |
| Blade Drive | Electric W/ Sensorless Vector Control |
| Blade Guides | Carbide & Ball Bearing Roller Guides |
| Upper Blade Guide | Hydraulically Positioned & Locking |
| Vises | Hydraulic, Full Stroking W/9-1/2" High X 15" Wide 60 Degree Face Plates |
| Auto Bar Feed Stroke Length | 48" |
| Max. Material Feed | 18' |
| Auto Bar Feed Creep Speeds | Up To 33 IPM |
| Cutting Fluid | Two Gallons Soluble Oil |
| Column | Tilting for Miter Cutting Up To 60 Degree L/R of Vertical |
| Blade Tension | Hydraulically Controlled - 45,000 PSI Max. |
| Table Height Above Floor | 40" |
| Work Load Capacity | 8,000 Lbs |
| Approx. Machine Dimensions | 94" x 99.2" x 90.8" |
