2025 Machinery Works, Inc. / JIH-I VMC10.5

We are pleased to offer you one new cnc traveling column cnc vertical machining center for your project. We can build and supply four machines which should meet your requirements for production. Pricing above is for one machine and is quoted FOB USA port with import duties and tariffs paid. Any change in current tariffs will be added or deleted at the time of importation.

Included:

Installation of each machine with training

Fanuc Oimf CNC Control with manual pulse generator

Scales on all axis, x,y,z

Coolant with tank

Semi enclosure to keep coolant contained

Includes 16" 4th axis indexer with tailstock to hold and rotate the part

Wired 220v/3/60 cycle

The work holding for the tube support is being looked at and would be at an additional charge.

1. The base is fabricated from heavy gauge steel plates and scientifically reinforced, allowing for solid support for the column and work pieces.

2. Traveling column design features increased machining efficiency and accuracy.

3. The oversized box-type column is manufactured from high quality cast iron.

4. Large diameter ball screw on x-axis is firmly supported to eliminate self-deflection problems.

5. 3 axis adopt 45 mm P class high precision linear guide ways; X axis features 8 blocks, Y and Z axis are 6 blocks.

6. Automatic lubricator delivers lubrication oil to all linear ways and ball screws.

7. Y-axis & X-axis ball screws are direct coupled with drive motors, featuring no backlash, high transmission efficiency and high accuracy.

Traveling Column

• The machine is designed with a travelling column and a fixed table.

• With the travelling column configuration,work piece weight will not affect the transmission system. As a result,consistent machining accuracy can be achieved.

• Each linear way on the Y-axis is fitted with 3 sliding blocks to assure ultra-high stability when the Y-axis is moving.
